Twilled Woven Style

Twilled weave means Wire Cloth in which each warp wire-and each shute wire passes successively over-and under the two adjacent wires -- in both the warp-and shute directions. This over-and under movement is shifted one wire with each pass of the shuttle. This pattern permits the weaving of heavier wires in varying meshes.

Materials:SS 302, SS 304, SS 304L, SS 316, SS 316L, SS 321-and SS 430-and brass-or copper, some alloys.

Roll Width: 36", 40", 48", 60"

Roll Length: 25Ft, 50Ft-and 100Ft

Features:

Stainless steel twilled weave wire mesh have the features of wear resistance, heat-resisting, acid-resisting, alkali resisting, durable structure,-and corrosion resistance.

Meantime stainless steel woven mesh also have high temperature resistance, good electric conductivity-and washing resistance.

Application:

Stainless steel woven wire mesh is widly used in mining, petroleum, chemical industry, food industry , pharmaceutical industry-and sifting-and screening mesh in chemical-and chemical fiber industry.
